Carbon Fiber PEEK Unidirectional Daim kab xev

Taw qhia

Carbon Fiber PEEK Unidirectional Daim Kab Xev yog cov khoom siv sib xyaw ua ke uas zoo kawg nkaus lub zog thiab nruj ntawm cov pa roj carbon fiber ntau nrog cov thermal thiab tshuaj tiv thaiv zoo ntawm Polyether Ether Ketone (PEEK) resin. Daim kab xev tshwj xeeb no ua rau txoj kev loj hlob ntawm cov khoom sib zog thiab muaj zog tsim cov khoom tsim thaum tuav cov khoom zoo.

Ntsiab nta

Siab zog thiab nruj: Carbon fiber muab qhov zoo tshaj plaws tensile lub zog thiab rigidity, kom ntseeg tau tias cov khoom tuav nws cov duab thiab kev ua tau zoo nyob rau hauv siab loads.

Zoo heev thermal stability: PEEK resin tuaj yeem tiv taus kev siv tas li ntawm qhov kub txog li 260 degree, ua rau nws tsim nyog rau kev siv hauv qhov chaw kub kub.

Cov tshuaj tiv thaiv zoo: Nws tuaj yeem tiv taus ntau yam tshuaj, suav nrog cov kuab tshuaj, cov kua qaub, thiab cov hauv paus, ua rau nws zoo tagnrho rau kev ua haujlwm hnyav.

Lightweight Design: Muab piv rau cov khoom siv hlau, cov khoom siv carbon fiber ntau txo cov khoom hnyav thaum tuav lossis txhim kho cov txheej txheem.

Kev ua kom yooj yim: Hom ntawv prepreg tso cai rau kev tsim khoom yooj yim, haum rau ntau yam txheej txheem molding xws li lub tshuab nqus tsev ntim khoom thiab automated daim kab xev tso.

Cov yam ntxwv ntawm cov khoom

1.Width: 1mm - 304mm

2.Thickness: 0.13mm - 0.15mm

3.Fiber Areal Nyhav (FAW): 75-150 gsm

4.Resin Cov ntsiab lus (RC): 35-50 wt%

5.Tensile Modulus: 130 GPa (ASTM 3039)

6.Tensile zog: 2000 MPa (ASTM 3039)

Cov khoom ntawm PEEK Unidirectional Daim kab xev

1. Corrosion Resistant

2. Qhov ntev ruaj khov

3.Low Shrinkage, Tsawg dej nqus, thiab qis Coefficient ntawm Thermal Expansion

4.Cov khoom tuaj yeem txhawb nqa los ntawm kev overmolding

5.Recyclable thiab Reusable

6.Zoo heev Fatigue Resistance

Daim ntawv thov

Carbon Fiber PEEK Unidirectional Daim kab xev pom kev siv dav hauv ntau qhov chaw:

Aerospace: Siv rau hauv cov khoom siv dav hlau thiab cov qauv tsim los txhim kho kev ua haujlwm thiab roj efficiency.

Automotive Kev Lag Luam: Siv nyob rau hauv cov tsheb sib tw thiab cov tsheb ua haujlwm siab rau cov khoom sib sib zog nqus, txhim kho kev ceev thiab kev tuav muaj peev xwm.

Cov cuab yeej kho mob: Ua kom muaj kev nyab xeeb thiab kev ntseeg siab thaum lub sijhawm ua haujlwm kub kom tsis muaj menyuam.

Electronics: Siv los tsim kom muaj zog thiab lub teeb yuag enclosures thiab brackets rau cov khoom siv hluav taws xob.
