Siv cov khoom siv tseem ceeb
Siv cov khoom siv tseem ceeb
Cov qauv poob phaus poob
Khoom Taw Qhia
HG {{{{{{{4 4}}}}}}}}}}}}}}} Cov khoom siv tsis muaj zog ntawm lub teeb ntawm tsuas yog 0.4. Nws muaj ib tus qauv ntawm tus neeg sawv cev ib leeg thiab tsim nyog rau cov ntawv thov yuav tsum tau txo qhov hnyav.
Nrog cov khoom ntiag tug zoo heev, nws yog qhov tsim nyog rau adhering rau hlau, iav, ceramics, ntau cov khoom tawv tawv, ntau cov khoom siv sib xyaw.
Khoom Qhia Txog Khoom
|
Kev tshwm sim |
Av nplaum |
|
|
Viscosity (25 degree) |
mpa s |
Av nplaum zoo li |
|
Ceev (25 degree) |
g / cm3 |
0.40 |
|
Flash taw tes (Pensky-Martens) |
tiv kis |
> 200 |
|
Shear zog (DIN 53283) |
||
|
Kho: 30 min / 150 degree |
||
|
Kuaj ntawm 23 Qib |
N / hli2 |
> 20 |
Khoom nta
|
Txee lub neej nyob rau hauv khov -20 degree |
12 lub hlis |
|
Txee lub neej nyob rau hauv khov 3-5 degree |
6 lub hlis |
|
Nrib Los Ntawm Cov Khoom |
Nrib pleb hauv qab nplaim taws ua pa roj carbon monoxide thiab carbon dioxide |
|
Nkim pov tseg |
Thov sab laj cov kev cai hauv zos |
Nto Kho
Txhawm rau kom ua tiav lub zog siab tshaj plaws, nws yog qhov tseem ceeb kom ua kom huv si txoj kev sib raug zoo thiab tshem tawm cov roj lossis xeb siv acetone lossis trichlorethylene. Cawv, roj av, los yog ntoo qab zib yuav tsum tsis txhob siv rau kev ntxuav. Sandblasting lossis cov tshuab sib tsoo tuaj yeem ua haujlwm kom nce thaj tsam thaj tsam thiab txhim kho kev sib koom tes. Ib qho ntxiv, nws raug nquahu kom nrhiav cov lus qhia los ntawm peb lub tuam txhab cov kws tshaj lij rau cov tshuaj kho cov txheej txheem saum npoo av.
Khoom Siv Cov Khoom Siv Kua nplaum
Rau cov loj-thaj chaw lossis kev tsim tawm, muaj cov khoom siv cov khoom siv txhua yam muaj thiab thov sab laj peb lub tuam txhab cov khoom lag luam rau kev xaiv.
Kho cov mob
|
Qho so |
tiv kis |
120 |
140 |
150 |
160 |
180 |
|
Sij hawm |
Lub min |
60 |
45 |
30 |
20 |
10 |
|
Shear zog (23 degree) |
N / hli2 |
20－23 |
20－25 |
23－25 |
23－25 |
23－25 |
Qhov Chaw Xeem Ntawv
Yog tsis muaj lwm yam kev sib tham, ua rau raws li kev sib tham hauv qab no yog raws cov qauv xeem 100 x nias ally 170x25x, thiab kev sib cuag nto nyob raws 12.5x25 mm.
TEST
Shear kev nyuaj siab lub zog (tus nqi nruab nrab) ntawm ntau yam ntawm cov kev mob uas tuaj yeem ua: 30 min / 150 degree xeem cov cai ntawm 23 degree
Shear kev nyuaj siab lub zog thiab ntsuas kub (nruab nrab tus nqi)
Tshuaj Kho Mob: 30 Min / 150 Qib
Kuaj tom qab 10 feeb ntawm qhov ntsuas kub
Coefficient ntawm linear nthuav (VDE 304)
Ntawm 20 oc rau 60 oc 35 * {10-6 m / oc m
60 OC rau 100 OC 45 * {10-6 m / oc m
Hluav Taws Xob Corrosion
Kev Ua Haujlwm: A1
Lub cev mob tom qab kho
|
Hardness (Ntug Dej D) |
ASTM D -2240 |
85 |
|
Lub zog tensile |
ASTM D -638 |
18 n / hli2 |
|
Dab tsi yog khoov zog |
ASTM D -790 |
25 n / hli2 |
|
Dabtsi Yog Khoov Kuj |
ASTM D -790 |
2,500 n / hli2 |
|
Tawv muaj zog |
ASTM D -256 |
1.8kg-cm / cm2 |
|
Compressive lub zog |
ASTM D -695 |
40 n / hli2 |
|
Cov iav hloov cua txias |
ASTM D -648 |
125oC |
Muaj kev huv thiab kev nyab xeeb
Kev Nyab Xeeb Kev Nyab Xeeb thiab Kev Lom Zem
|
Ua Haujlwm Khaub Ncaws |
Yuav xav tau |
|
Hnab looj tes |
Yuav xav tau |
|
Lub tes tsho |
Pom zoo |
|
Tiv Thaiv Visor |
Yuav xav tau |
|
Ntshaw ntsej muag |
Tsis xav tau |
|
Kev tiv thaiv daim tawv nqaij ua ntej ua haujlwm thiab tom qab ntxuav tes |
Txhais tes qab zib los yog tshuaj pleev cov tshuaj pleev yuav tsum tau siv los ua cov yeeb yaj kiab tiv thaiv ntawm daim tawv nqaij |
Cov ntaub ntawv ntawm daim tawv nqaij
So cov ntaub ntawv nrog cov ntaub ntawv phuam so lossis ntsej muag ci thiab tom qab ntawd ntxuav nws nrog xab npum sov thiab tsis yog alkaline. Tsis txhob siv cov kuab tshuaj los ntxuav cov tawv nqaij kom tsis txhob ua xua.
Cov khoom siv nchuav rau hauv av
Tsuas yog siv xuab zeb lossis sawdust kom nqus cov ntaub ntawv. Koj tseem tuaj yeem siv cov khaub hlab muaj kev lag luam lossis muaj ntaub ntawv los so huv. Tsis txhob siv cov kuab tshuaj kom nchuav rau hauv av thiab huv si. Muaj kev pheej hmoo ntawm hluav taws.
Thawj pab kev cai
Thaum muaj kev sib tsoo nrog cov khaub ncaws, tawv tawv, lossis lawv cov pa tawm ntawm qhov chaw muaj kev cuam tshuam rau kev kho mob. Yog tias kev sib txaws ntawm lwm qhov chaw ntawm daim tawv nqaij, so nrog cov nqaij ntsej muag, ntxuav thaj chaw nrog dej sov thiab tshuaj ntxuav tes, thiab siv tshuaj pleev tes los tswj cov tawv nqaij. Yog tias tsis muaj kev xav, nrhiav kev pab kho mob thaum muaj xwm ceev. Ib qho ntxiv, yuav tsum xav txog cov muaj peev xwm hlawv thiab ua kom muaj kev phom sij kub siab, thiab ua kom muaj kev phom sij ua haujlwm thiab cov neeg teb xov tooj nyab xeeb.
